Nominal Pipe size
|
A
|
d
|
D
|
|
ANSI 150 LBS
|
t
|
ANSI 150 LBS
|
| 1 (25) |
89 |
19 |
3 |
51 |
| 1 1/2 (40) |
102 |
34 |
3 |
73 |
| 2 (50) |
114 |
46 |
3 |
92 |
| 2 1/2 (65) |
130 |
59 |
3 |
105 |
| 3 (80) |
140 |
74 |
3 |
127 |
| 4 (100) |
165 |
94 |
3 |
155 |
| 6 (150) |
203 |
140 |
5 |
212 |
| 8 (200) |
228 |
190 |
5 |
270 |
| 10 (x250) |
280 |
238 |
6 |
323 |
| 12 (x300) |
305 |
238 |
6 |
381 |
Note:
- Steel frame :ASTM A234 grade WPB in
compliance with ANSI B16 28
- Steel bend according to SCH 40 .
- Flange IS 2062 in compliance with ANSI B16.5/
class 150lbs; JIS 10K or DIN is also available on request.
- Standard : three fixed flanges three loose flange
and one fixed flange or two loose flanges is on request.
- Lining : PP in compliance with ASTM
F-1545.
